Rahmenset
Rahmen
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Gabel
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Steuersatz
FSA 1-1/2" Integrated Aluminium Cup
Ebike
Display
Mahle Pulsar One monochrome ANT+ LEV
Ladegerät
Mahle Active Charger up to 4A
Remote
Mahle ONE Head Unit (BT/ANT+)
Übersetzung
Kurbel
Shimano Cues U6040 34x50t
Kassette
Shimano CS-LG400 11-39t 10-Speed
Schaltwerk
Shimano Cues U6020 SGS Shadow
Cockpit
Lenker
OC Road Performance RP21 Alu SL, Reach 80, Drop 125
Vorbau
OC Road Performance RP10, -8º
Bremsen
Bremsen
Shimano U6030 Hydraulic Disc
Laufräder
Laufradsatz
Alloy, Tubeless, 700c, 21c
Reifen
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Vorderradachse
Orbea Thru Axle 12x100mm M12x2 P1 Lite
Rear Hub
Orbea Thru Axle 12x142mm M12x2 P1 Lite
Komponenten
Sattelstütze
OC Performance XP10-S Carbon, 27.2mm, Setback 20
Zubehör
Scheinwerfer
Front position light, on display holder, COB Led, On/Off, 60 Lumen, ECE50.
Rücklicht
Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
Lenkerband
Orbea Anti-Slippery/Shock Proof
Achtung! Dieses Fahrrad wird ohne Pedale geliefert.
