Technische Details
-
frame: Ryal Alloy Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 160 mm
-
fork: Rock Shox Psylo Silver RC, 160 mm Travel
-
fork-suspension-travel: 160
-
rear-shock: Rock Shox Deluxe Select+, 210 x 55 mm
-
rear-shock-suspension-travel: 160
-
gear system: Shimano XT M8100, Shadow Plus 12-Speed
-
shift-levers: Shimano Deore 6100 Speed Rapidfire Plus, 12-Speed
-
number of hears: 12
-
brakes: Shimano MT520, SM-RT66 203 mm
-
Wheelset: Megamo 29 SL 30 ASY, Aluminium Rim, 15x110/12x148 mm
-
tires: Maxxis Assegai 29x2.5 EXO+ 3C MaxxTerra / Maxxis Minion DHR II 29x2.4 EXO+ 3C MaxxTerra
-
handlebar: Megamo AL, 35 x 800 x 12 mm
-
Stem: Megamo, 35 x 50 mm
-
saddle: Selle Royal SRX Open
-
crankset: FSA Avinox Chainring 36T 12-Speed, Crankset 160 mm
-
sprockets: Shimano Deore M6100, 10-51T
-
motor: Avinox M2, 110Nm, 1100W
-
battery: Avinox 800 Wh Removable
-
display: Avinox DPC100
-
charger: Avinox 4A
-
stack: 617
-
reach: 442
-
seat-tube-length: 400
-
seat-tube-angle: 77
-
top-tube-length: 584
-
head-tube-lenght: 100
-
head-tube-angle: 63.5
-
wheelbase: 1233
-
chainstay-length: 450
-
bottom-bracket-height: 348
-
bottom-bracket-drop: 30
