| Framebeschreibung |
Reason Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 160 mm |
| Framecolor |
FC20 |
| Framematerial |
FM40 |
| Frametype |
FT90 |
| Gabel |
Fox 36 Kashima 160 |
| Fork suspension travel in mm |
160 |
| Rear-shock |
Fox Float X Kashima |
| Rear suspension travel in mm |
160 |
| Schaltwerk |
Shimano XT M8100 12s |
| Shift-levers |
Shimano XT M8100 12s |
| Front-derailleur |
|
| Number of gears. Leave blank for stepless shifts. |
12 |
| Gearsystem |
GS10 |
| Bremsen |
XT 4 Piston 203 / 203 |
| Brake-front |
XT 4 Piston 203 / 203 |
| Brake-rear |
XT 4 Piston 203 / 203 |
| Brake-levers |
XT 4 Piston 203 / 203 |
| Brake-lever-front |
XT 4 Piston 203 / 203 |
| Brake-lever-rear |
XT 4 Piston 203 / 203 |
| Brake-disc |
203 mm |
| Brake-disc-front |
203 mm |
| Brake-disc-rear |
203 mm |
| Attributee Brake |
BR25 |
| Complete wheelset (hub, spokes, rims)beschreibung |
DT Swiss M 1900 // Maxxis 29 x 2.4 Minion DHR II / 29 x 2.5 Assegai |
| Felgen |
DT Swiss M 1900 |
| Rim-front |
DT Swiss M 1900 |
| Rim-rear |
DT Swiss M 1900 |
| Reifen |
Maxxis 29 x 2.4 Minion DHR II / 29 x 2.5 Assegai |
| Tire-front |
Maxxis 29 x 2.4 Minion DHR II / 29 x 2.5 Assegai |
| Tire-rear |
Maxxis 29 x 2.4 Minion DHR II / 29 x 2.5 Assegai |
| Naben |
DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Hub-front |
DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Hub-rear |
DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Spokes |
DT Swiss 370 Ratchet LN 18, Front axle 15 x 110 mm, Rear axle 12 x 148 mm BOOST |
| Wheelsize |
WS29 |
| Lenker |
Race Face ERA carbon |
| Vorbau |
Satori new URSA |
| Headset |
|
| Grips |
Race Face Half Nelson |
| Aerobar |
|
| Handlebar-tape |
|
| Sattel |
Fizik Aidon 145 X5 |
| Seat-post |
Fox Transfer Kashima |
| Seat-clamp |
|
| Kurbelgarnitur |
FSA Alloy |
| Bottom-bracket |
|
| Drive |
|
| Sprockets |
Shimano XT 8100, 10-51T |
| Pedals |
|
| Drive Types |
DT10 |
| Front-light |
|
| Rear-light |
|
| Dynamo |
|
| Rack |
|
| Front-rack |
|
| Mudguards |
|
| Chainguard |
|
| Stand |
|
| Lock |
|
| Street permission |
ST10 |
| Motor Manufacturer |
|
| Motor Position |
MP20 |
| Motor Type |
MT25 |
| Motor |
DJI AVINOX M1 / 120 Nm / 1000W / 850 W |
| Battery Mounting |
BM30 |
| Battery Type |
BT10 |
| Battery Voltage |
BV90 |
| Akku |
DJI AVINOX 800 Wh |
| Battery capacity in Wh |
800 |
| Display |
DJI AVINOX DP100 |
| Ladegerät |
DJI AVINOX 4A Charger |
| Bodysize |
|
| Recommendation for minimum height (cm) |
|
| Recommendation for maximum height (cm) |
|
| Targetgroup |
TG10 TG20 |
| Operation Purpose |
OP40 |
| Operation Area |
OA32 |
| Net weight without packaging (kg). Enter value only |
|
| Permissible total weight (kg). Enter value only |
|
| Assembly Condition |
|
| Country of origin. Specification according to ISO 3166-2 format (e.g. DE, AT). |
|
| Customs-tariff-number |
|
| Packaging-length-mm |
|
| Packaging-width-mm |
|
| Packaging-height-mm |
|
| Packaging-weight-g |
|
| Stack (mm) |
644 |
| Reach (mm) |
511 |
| Mm |
455 |
| Degree |
78 |
| Mm |
648 |
| Mm |
140 |
| Degree |
64,5 |
| Mm |
|
| Degree |
|
| Mm |
|
| Mm |
|
| Mm |
|
| Degree |
|
| Mm |
1307 |
| Mm |
|
| Mm |
457 |
| Mm |
|
| Mm |
|
| Mm |
345 |
| Mm |
33 |
| Mm |
|
| Mm |
|
